Zoeller Model D57 Sump Pump Description

Our Model D57 Sump Pump is an all cast iron sump pump designed to remove unwanted groundwater in basement sump applications. The professional-grade, 3/10 HP D57 is the industry standard when it comes to cast iron sump pumps. Known as the “Mighty-Mate,” the D57 is a fully automatic float-operated sump pump. The white polypropylene float is solid so it cannot become waterlogged. This ensures that it is always buoyant and able to turn the pump on when necessary.

The Model 57’s switch case, motor housing, pump housing, and base are each constructed of cast iron. Additionally, the Model 57 is designed with a cast iron vortex impeller allowing solids to pass freely through the pump. The pump’s identification tag, float guard, handle, switch arm, and hardware are made of non-corrodible stainless steel. This attention to detail ensures that the Model 57 is able to withstand the most demanding basement sump applications.

Zoeller Model D57 Sump Pump Features and Benefits

• Oil-Filled Motor and Cast Iron Motor Housing for Optimal Heat Dissipation which Prevents the Pump from Overheating
• Automatic Pump with a Time-Tested, Reliable, Preset, Built-In Snap Action Switch that Makes for Easy Installation
• Cast Iron Vortex Impeller to Allow Free Passage of Solids which Prevents Clogging and Lessens Downtime
• Stainless Steel Float Guard that Prevents Material or Debris from Collecting on the Float Ensuring Proper Operation Every Time
• Powder-Coated Epoxy Finish Provides Corrosion-Resistance and Extends the Life of the Pump in Harsh Environments
• Stainless Steel Screws, Switch Arm, Guard, Handle and Hardware to Prevent Rust and Corrosion Over the Life of the Pump
• 100% Factory Tested - Every Pump is Submerged in Water and Tested at the Factory to Ensure that it Performs as Expected when you Receive it
• Comes with a 3-Year Limited Warranty Giving you Protection Over Your Investment and the Peace of Mind you Expect in a Quality Product

Zoeller 57-0003 Sump Pump Specifications

• VOLTAGE: 1ø, 230V, 60Hz
• HORSEPOWER: 0.33 HP
• AMP DRAW (full load): 4.8
• MOTOR TYPE: Shaded Pole
• RPM: 1550 RPM
• MAXIMUM HEAD: 19'
• MAXIMUM CAPACITY: 43 GPM
• SWITCH TYPE: Automatic
• SWITCH 'ON' LEVEL: 7-1/4" (18.4 cm)
• SWITCH 'OFF' LEVEL: 3" (7.6 cm)
• DISCHARGE PIPE SIZE: 1-1/2" NPT
• MAXIMUM SOLIDS HANDLING: 1/2" Spherical Solid
• IMPELLER TYPE: Cast Iron, Non-Clogging Vortex
• CORD LENGTH: 9'
• BODY CONSTRUCTION: Cast Iron
• MAXIMUM OPERATING TEMPERATURE: 130°F (54C)

Zoeller Model D57 Sump Pump Performance Curve
