SymCom Model 50R-400-ALT Alternating Relay 380-480V Surface
SymCom Model 50R-400-ALT Alternating Relay 380-480V Surface
SKU : MSR50R400ALT
In Stock Quantity:0
:
Brand
:
Shipping calculated at checkout.
Couldn't load pickup availability
Description
Description
Littelfuse 50R-400-ALT Alternating Duplex Pump Description
The 50R-400-ALT alternating relays are used to alternate between two loads, most commonly in duplex pumping and compressor applications to balance the runtime of both loads
When used in single float applications, the alternating relay changes state after the float switch opens*, forcing the other pump to run the next time the float closes. When used in dual float applications, the alternating relay will allow both pumps to run simultaneously when the lead and lag floats are both closed.
An adjustment knob provides the option to force one pump to run every time the float switch is closed. This is helpful when one pump has been removed for repair or for test purposes. A built-in debounce feature prevents the alternating relay from changing state if the float contact bounces momentarily.
Littelfuse 50R-400-ALT Alternating Duplex Pump Relay Typical Applications
- Duplex Control Panels
Littelfuse 50R-400-ALT Alternating Duplex Pump Relay Features
- Alternates Between Two Loads
- Solid-State Reliability
- Compact Size
- Debounce Time Delay
- Compatible with Single or Dual Float Applications
- 600VAC Control Contacts
- 10 Amp General Purpose Relay Rating
- UL Listed
- CE Marked
- 5-Year Warranty
- Made in the USA
Specifications
Specifications
Littelfuse 50R-400-ALT Alternating Relay Duplex Pump Specifications
Supply Voltage . . . . . . . . . . . . 380-480 VAC
Supply Current . . . . . . . . . . . . . 40mA
Control Input Impedance (min). . . . . . . . . . . . .1MΩ
Output Contact Rating
- Pilot Duty. . . . . . . . . . . . . . . . . . . . . . . . . . . . 470VA @ 600VAC
- General Purpose. . . . . . . . . . . . . . . . . . . . . . . . . . 10A
- Debounce Time Delay . . . . . . . . . . . . . . . . . . . . . . . . . . 1 second
Maximum Input Power . . . . . . . . . . . . . 5 Watts
Terminal Torque . . . . . . . . . . . . . 7 in.-lbs.
Wire Gauge . . . . . . . . . . . . . 12-18AWG
Safety Marks
- UL . . . . . . UL508 (File #E68520)
- CE . . . . . . . . . . . IEC 60947
Weight . . . . . . . . . . . . . . . . . . . . . . . . 15.68 oz.
Mounting Method . . . . . . . . . . . #8 screws
