SymCom 80 Reverse-Phase Relay/171-528V/Fast-On Terminals 3-Phase Voltage Monitors

The Model 80 is designed to continuously monitor for ABC phase sequencing of 190-480VAC, 3-phase systems. Critical applications include fan motors, scroll compressors, grinders, conveyor systems, elevators and escalators. A solid-state sensing circuit energizes a Form C relay and illuminates an LED indicator when the proper phase sequence is applied.

SymCom 80 3-Phase Voltage Monitor Features

• Protects 3-phase motors from phase reversal• 0.5 second response time• Relay status LED• Automatic reset• CSA approved for use in Canada and US• 5-year warranty• Made in the USA

SymCom 80 3-Phase Voltage Monitor Technical Details

• Protective Relay Functions
• • The equipment shall provide protection against phase reversal.
• Capabilities and Features
• • Inputs
  • • The equipment shall accept one of the following:
    • Voltage range of 171-264VAC
    • Voltage range of 342-528VAC
  • Outputs
  • • The equipment shall include one Form C (SPDT) output relay.
    • Contacts pilot duty rated 480VA@240VAC.
    • Contacts general purpose rated 10A@240VAC.
  • Functional Specifications
  • • The equipment shall provide 0.5 second response time for a reverse-phase fault condition.
    • The equipment shall have an indicator light. The indicator light has the capability to indicate whether the phase monitor is in run mode or fault mode (phase reversal).
• Electromagnetic Compatibility
• • The equipment shall be immune to electrical fast transient bursts exceeding IEC 61000-4-4, Level 2. Specified limits shall be 2kV.
  • The equipment shall be immune to electrical surges per IEC 61000-4-5, Level 4. Specified limits shall be Level 3, 4kV line-to-line and line-to-ground.
• Dielectric Isolation: Equipment withstands an alternating current potential of 1000V plus twice the rated voltage of the equipment for 1 minute without breakdown between uninsulated live parts and the enclosure with the contacts open and closed; between terminals of opposite polarity with the contacts closed; and between uninsulated live parts of different circuits.
• Environmental Requirements
• • The equipment shall operate continuously without derating in ambient temperatures of -20° to 50°C (-4° to 122°F).
  • The equipment shall operate continuously without derating in relative humidity of 10% up to 95% non-condensing per IEC 68-2-3.
• Dimensions: The equipment dimensions shall not exceed 2” high X 2” wide X 1.25” deep.
• Mounting: The equipment shall be surface mountable.
