Myers 4" Submersible Rustler Series Pump Description

Precision-Engineered, corrosion-resistant pumps in 5, 7/8, 10/12, 20 and 30 GPM deliver efficient, dependable performance even in rough, aggressive water. Head up to 650 feet and capabilities to 45 GPM. Built to deliver long-term, trouble-free service.

These pumps feature the proven SignaSeal staging system. Floating impeller design resists sand and reduces sand locking.

Myers 4" Submersible Rustler Series Pump Application

• Residential Water Systems
• Industrial Water Systems
• Commercial Water Systems
• Multiple Housing and Farm Clean Water Use

Myers 4" Submersible Rustler Series Pump Features

• Proven Staging System: Our proven SignaSeal Staging System Incorporates a Harder-than-Sand Ceramic Wear Surface that when Incorporated with our Floating Impeller Design, Greatly Reduces Problems with Abrasives, Sand Lock-Up and Running Dry.
• Discharge: Corrosion-Resistant Fiberglass-Reinforced Thermoplastic for Durability in Aggressive Water. Large Octagon Wrench Area for Ease of Installation.
• Discharge Bearing: Exclusive Self-Lubricating Nylatron Bearing Resists Wear from Sand.
• Intake: Corrosion-Resistant Fiberglass-Reinforced Thermoplastic for Durability in Aggressive Water.
• Shaft: Positive Drive from 7/16" Hexagonal Heavy-Duty 300 Grade Stainless Steel.
• Coupling: Stainless Steel Press Fit to Pump Shaft. Couples to all Standard NEMA Motors.
• Shell: Crimped Shell.
• Hardware: All Screws, Washers and Nuts are Corrosion-Resistant 300 Grade Stainless Steel.
• Check Valve: Spring-Loaded Check Valve.
• Cable Guard: Corrosion-Resistant Stainless Steel Guard Protects Motor Leads. Tapered Ends Prevent Pump from Catching on Well.
• Intake Screen: Molded-In Screen.
• Pentek XE Series Motor: 2 and 3 Wire NEMA Standard all Stainless Steel Construction Water-Filled Motors.

Myers 3NFL102-12-P4 Rustler Series Pump Specifications

Water Well Motor
• BODY CONSTRUCTION: 304 Stainless Steel
• HORSEPOWER: 1.0 HP
• VOLTAGE: 1ø, 230V
• FULL LOAD AMPS: 9.1
• LEAD: 3-Wire
• CONTROL BOX REQUIRED
Water Well Pump End
• Discharge Size: 1.25" NPT
• NOMINAL FLOW RATING: 12 GPM
• HORSEPOWER: 1.0 HP
• MAXIMUM CAPACITY: 18 GPM
• MAXIMUM HEAD: 450 ft.
• STAGES: 11
• IMPELLER DESIGN: Floating Stack
• IMPELLER MATERIAL: Self-Lubricating Noryl
• BODY MATERIAL: Stainless Steel

Myers 4" Submersible Rustler Series Pump Curve

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Myers 4" Submersible Rustler Series Pump Product Resources

Download Myers Rustler Series Pump Specifications

Download Myers Rustler Series Pump Manual
