Myers S Series Submersible Pump Description

The S Series 4" Submersibles have been a successful entry in the Myers well pump line for many years and have a history of tremendous reliability. The all stainless steel construction is ideal for extreme water conditions and easily resists harmful corrosion. The S Series subs are also available with high-performance Pentek motors for the very best in efficiency and trouble-free operation.

Myers S Series Submersible Pump Typical Application

• Residential Water Systems
• Industrial Water Systems
• Commercial Water Systems
• Multiple Housing and Farm Clean Water Use

Myers S Series Submersible Pump Features

• Smooth and Quiet- Precision Crafted, 4" Submersible Well Pumps for Quieter Operation.
• Stainless Steel Everywhere- Shell, Impellers, Discharge Bowl, Shaft and Coupling, Wear Ring and Suction Screen.
• Tough in Any Situation- Stainless Steel Impellers Stand Tough against Sand and Grit - Nothing but the Best.
• All Powerful- Features Application-Matched Pentek Motors for Just the Right Mix of Performance and Efficiency.
• No Slip Ups- Built-In Hook Assembly Keeps Pump Safe from Slip.

Myers 2S52-10-P4 S Series Submersible Pump Specifications

Water Well Motor
• BODY CONSTRUCTION: 304 Stainless Steel
• HORSEPOWER: 0.5 HP
• VOLTAGE: 1ø, 230V
• FULL LOAD AMPS: 6.0
• LEAD: 2-Wire
Water Well Pump End
• DISCHARGE SIZE: 1.25" NPT
• NOMINAL FLOW RATING: 10 GPM
• HORSEPOWER: 0.5 HP
• MAXIMUM CAPACITY: up to 14 GPM
• MAXIMUM HEAD: up to 210 ft.
• IMPELLER DESIGN: Floating Stack
• IMPELLER MATERIAL: 304 Stainless Steel
• BODY MATERIAL: 304 Stainless Steel

Myers S Series Submersible Pump Curve

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Myers S Series Submersible Pump Product Resources

Download Myers S Series Pump Specifications

Download Myers S Series Pump Manual
