Myers 2NFL152-20-P4 Submersible Rustler Series Pump 20 GPM 1.5 HP 230V 2-Wire 1PH

Myers 2NFL152-20-P4 Submersible Rustler Series Pump 20 GPM 1.5 HP 230V 2-Wire 1PH

Usually ships within 2 weeks

SKU : MYR2NFL152-20-P4

In Stock Quantity:-1

:
Brand : Myers
$1,926.29 USD
Shipping calculated at checkout.

Description


Myers 4" Submersible Rustler Series Pump Description

Precision-Engineered, corrosion-resistant pumps in 5, 7/8, 10/12, 20 and 30 GPM deliver efficient, dependable performance even in rough, aggressive water. Head up to 650 feet and capabilities to 45 GPM. Built to deliver long-term, trouble-free service.

These pumps feature the proven SignaSeal staging system. Floating impeller design resists sand and reduces sand locking.

Myers 4" Submersible Rustler Series Pump Application

  • Residential Water Systems
  • Industrial Water Systems
  • Commercial Water Systems
  • Multiple Housing and Farm Clean Water Use

Myers 4" Submersible Rustler Series Pump Features

  • Proven Staging System: Our proven SignaSeal Staging System Incorporates a Harder-than-Sand Ceramic Wear Surface that when Incorporated with our Floating Impeller Design, Greatly Reduces Problems with Abrasives, Sand Lock-Up and Running Dry.
  • Discharge: Corrosion-Resistant Fiberglass-Reinforced Thermoplastic for Durability in Aggressive Water. Large Octagon Wrench Area for Ease of Installation.
  • Discharge Bearing: Exclusive Self-Lubricating Nylatron Bearing Resists Wear from Sand.
  • Intake: Corrosion-Resistant Fiberglass-Reinforced Thermoplastic for Durability in Aggressive Water.
  • Shaft: Positive Drive from 7/16" Hexagonal Heavy-Duty 300 Grade Stainless Steel.
  • Coupling: Stainless Steel Press Fit to Pump Shaft. Couples to all Standard NEMA Motors.
  • Shell: Crimped Shell.
  • Hardware: All Screws, Washers and Nuts are Corrosion-Resistant 300 Grade Stainless Steel.
  • Check Valve: Spring-Loaded Check Valve.
  • Cable Guard: Corrosion-Resistant Stainless Steel Guard Protects Motor Leads. Tapered Ends Prevent Pump from Catching on Well.
  • Intake Screen: Molded-In Screen.
  • Pentek XE Series Motor: 2 and 3 Wire NEMA Standard all Stainless Steel Construction Water-Filled Motors.

Specifications

Myers 2NFL152-20-P4 Rustler Series Pump Specifications

    Water Well Motor
  • BODY CONSTRUCTION: 304 Stainless Steel
  • HORSEPOWER: 1.5 HP
  • VOLTAGE: 1ø, 230V
  • FULL LOAD AMPS: 11
  • LEAD: 2-Wire
    • Water Well Pump End
  • DISCHARGE SIZE: 1.25" NPT
  • NOMINAL FLOW RATING: 20 GPM
  • HORSEPOWER: 1.5 HP
  • MAXIMUM CAPACITY: 27.5 GPM
  • MAXIMUM HEAD: 360 ft.
  • STAGES: 11
  • IMPELLER DESIGN: Floating Stack
  • IMPELLER MATERIAL: Acetal
  • BODY MATERIAL: Stainless Steel

Myers 4" Submersible Rustler Series Pump Curve


WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Resources

Myers 4" Submersible Rustler Series Pump Product Resources


Download Myers 4" Submersible Rustler Series Pump Data Sheet

Download Myers 4" Submersible Rustler Series Pump Manual
