Littelfuse Model ALT-230-S-SW Alternating Duplex Pump Relay with Switch 95-125V 8-pin Plug-in

Littelfuse Model ALT-230-S-SW Alternating Duplex Pump Relay with Switch 95-125V 8-pin Plug-in

Usually ships within 1 week

SKU : MSRALT230SSW

In Stock Quantity:0

:
Brand : Littelfuse/Symcom
$81.78 USD
Shipping calculated at checkout.

Description

Littelfuse ALT-230-S-SW Alternating Duplex Pump Relay With Switch Product Description

Model ALT-230-S-SW alternating relays are used to alternate between two loads. The ALT is commonly used in duplex pumping applications to balance the runtime of both pumps.

The Model ALT-S is used in single high level float applications. When the float switch opens, the alternating relay changes state forcing the other pump to run the next time the float closes

Littelfuse ALT-230-S-SW Alternating Duplex Pump Relay WIth Switch Typical Applications

  • Duplex Control Panels

Littelfuse ALT-230-S-SW Alternating Duplex Pump Relay With Switch Features

  • Alternates Between Two Loads
  • Solid-State Reliability
  • Compact Size
  • Debounce Time Delay
  • SPDT or Cross Connected
  • Optional Manual/Auto Mode Switch
  • UL Listed
  • CE Marked
  • 5-Year Warranty
  • Made in the USA

Specifications

Littelfuse ALT-230-S-SW Alternating Duplex Pump Relay Specifications

Line Voltage . . . . . . . . . . . . . . 195-250 VAC

Supply Current . . . . . . . . . . . . . . 40mA

Debounce Time Delay . . . . . . . . . . . . . . 0.5 second

Control Input Impedance (min)

  • 24. . . . . . . . . . . . . . . . . . . . .10kΩ
  • 115. . . . . . . . . . . . . . . . . . . . 56kΩ
  • 230. . . . . . . . . . . . . . . . . . . . 100kΩ

Output Contact Rating . . . . . . . . . . . . . . . . . . . . . 480VA @ 240VAC

Temperature Range . . . . . . . . . . . . . . . . . . . . . -40° to 50°C (-40° to 122°F)

Maximum Input Power . . . . . . . . . . . 5 W

Safety Marks

  • UL (OT08PC octal socket required) . . . . . . UL508 (File #E68520)
  • CSA . . . . . . . . . . . . . . . . . . . . . . C22.2 No. 14 (File #46510)

Weight . . . . . . . . . . . . . . . . . . . . . . . . 6.08 oz.

Mounting Method . . . . . . . . . . . DIN rail or surface mount (plug into OT08PC socket)

The 600V socket can be surface mounted or installed on DIN Rail.


WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Resources

Littelfuse ALT-230-S-SW Alternating Duplex Pump Relay With Switch Resources


Littelfuse ALT-230-S-SW Product Specifications

Littelfuse ALT-230-S-SW Installation Bulletin

Littelfuse ALT-230-S-SW Engineering Bulletin
