Littelfuse CIO-DN-P Communications Module

Littelfuse CIO-DN-P Communications Module

Usually ships within 1 week

SKU : MSRCIODNP

In Stock Quantity:0

:
Brand : Littelfuse/Symcom
$429.85 USD
Shipping calculated at checkout.

Description

Littelfuse CIO-DN-P Communications Module Product Description

The CIO-DN-P module is a convenient, cost-effective DeviceNet™ interface device capable of providing discrete control and monitoring of motor starters, drives and other devices over a DeviceNet™ network.

The CIO-DN-P module provides four solid-state 24VDC inputs and two AC/DC rated relay outputs. The CIO-120-DN-P module provides four solid-state 120VAC inputs and two AC/DC related relay outputs. Both models can function as a stand-alone I/O device or can be connected to any model 777-P series unit to relay real-time information and permit overload control over the network.

Littelfuse CIO-DN-P Communications Module Features

  • Stand-Alone I/O or Use With 777-P Series Overload Relays
  • Four Digital Inputs
  • One Dedicated Reset Input
  • Two Outputs; One Form C, SPDT, One Form A, SPST-NO
  • Cyclical Messaging Read Real-Time Information:
    • Phase Currents
    • Average Current
    • Ground Fault Current
    • Phase Voltages
    • Average Voltage
    • Power Factor
    • Input States
    • Thermal Capacity
    • Restart Timer States
    • Fault Flags
    • Network Control
    • Open/Close Output Relays
    • Reset Overload
  • Ease in System Startup and Commissioning
  • Compact size; Reduced Field Wiring
  • DIN Rail or Surface Mountable
  • Unit Sets Flush With Side of 777-P Series Overload Relays

Specifications

Littelfuse CIO-DN-P Communications Module Specifications

Power Requirements

  • Voltage (nominal) . . . . . . . . . . . . . . . .24VDC
  • Current . . . . . . . . . . . . . . . . . . . 137mA (max.)
  • Power . . . . . . . . . . . . . . . . . . . 3.28 W (max.)

Voltage Range

  • CIO-DN-P. . . . . . . . . . . . . . . 12-24 VAC
  • Frequency. . . . . . . . . . . . 50/60Hz
  • Maximum Current . . . . . . . . . . . . . 2mA (typical)
  • Remote Reset . . . . . . . . . . . . . 24VDC, 10mA (min.), NO pushbutton

Output Characteristics (Form A & Form C Contactors)

  • Pilot Duty. . . . . . . . . . . . 480VA @ 240VAC, B300
  • General Purpose. . . . . . . . . . . . . . . . . . . . . . . 5A @ 240VAC

Temperature Range . . . . . . . . . . . . . -20° to 70°C (-4° to 158°F)

Relative Humidity . . . . . . . . . . . . . 10-95%, non-condensing

Wire Guage . . . . . . . . . . . . Solid or stranded, 12-20 AWG

Terminal Torque . . . . . . . . . 3 in.-lbs.

Hi-Potential Test (relays to other circuits) . . . . . . . . .(2 x rated V + 1000V for 1 minute)

Electrostatic Discharge (ESD) . . . . . . . . .IEC 61000-4-2, Level 3, 6kV contact, 8kV air

Radio Frequency Immunity, Radiated . . . . . . .150 MHz, 10V/m

Fast Transient Burst . . . . . . . . .IEC 61000-4-4, Level 3, 4kV input power

Safety Marks

  • UL, ULC Listed . . . . . . . . . UL508 (File #E68520)
  • CSA . . . . . . . . . . C22.2 (File #46510)

Enclosure . . . . . . . . .Polycarbonate

Weight . . . . . . . . . . . . . . . . . . . . . . . . 0.25lb

Mounting Method . . . . . . . . . . . . . . . DIN Rail or surface mount (w/two #8 screws)


WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Resources

Littelfuse CIO-DN-P Product Resources


Littelfuse CIO-DN-P Communications Module Product Specifications

Littelfuse CIO-DN-P Communications Module Installation Bulletin
