Franklin Electric 10FBT2C4 High Performance Cast Iron Booster Pumps 2.0 HP 115/230V 1 Phase 10 GPM
Franklin Electric 10FBT2C4 High Performance Cast Iron Booster Pumps 2.0 HP 115/230V 1 Phase 10 GPM
SKU : FEC95881025
In Stock Quantity:0
:
:
Brand
:
Shipping calculated at checkout.
Couldn't load pickup availability
Description
Description
Discontinued - All Booster Pumps
Franklin Electric High Performance Booster Pump Description
The BT4 horizontal booster pump is a low to medium capacity, high pressure, multi-stage unit. The BT4 can function as a multi-purpose high pressure pump, boosting water pressure from either city mains or private water systems. It is also ideal for applications that require more pressure than flow. Size ranges from 5 gpm to 25 gpm.
Franklin Electric Booster Pump Applications
- Pressure Boosting (from city mains or private water systems)
- Water Transfer and Circulation
- Lawn and Crop Irrigation
- Residential Lawn Sprinkler Systems
- Reverse Osmosis (MH/SS BT4)
- Filtration (SS BT4)
- Pressure Washing
- Poultry Houses
- Equipment Spray Cooling
- Evaporative Cooling System Misters
- General Purpose Plumbing
- Aeration
- Wash-Down Applications
- Commercial Water Features and Fountains
- Cisterns
Franklin Electric High Performance Booster Pump Features
- Stainless Steel Discharge on All Models with 1" NPT Outlet
- Stainless Steel or Cast Iron Bracket; Both with a Rugged Support for Horizontal or Vertical Mounting, a Handle for Portability and with 1" NPT Inlet
- Built with Franklin's Patented (U.S. Patent) 7,290,984 Tri-Seal Floating Stage System, Providing Maximum Efficiency, Longevity and Performance
- Acetal Impellers, Modified PPO Diffusers and 300-Series Stainless Steel Hub, Eye Seals, Shaft and Shell
- CI Version: Mechanical Seal with Phenolic/Ceramic Faces, Buna Elastomers and Stainless Steel Components
- SS Version: Mechanical Seal with Carbon/Ceramic Faces, FKM Elastomers and Stainless Steel Components
- Industry-Proven ODP Square-Flange 2-Compartment Motors are Easily Serviced or Replaced without either Dismantling the Pump End or Disturbing the Plumbing Connections
- High Service Factor, 1/2 to 3HP, 2-Compartment Dual-Voltage Motors; Three-Phase Inverter Duty Rated
- Maximum Fluid Temperature of up to 120°F/49°C; 150 PSI Maximum Working Pressure
Specifications
Specifications
Franklin Electric 10FBT2C4 Booster Pump Specifications
- DISCHARGE SIZE: 1.0" FNPT
- INLET SIZE: 1.0" FNPT
- MAXIMUM CAPACITY: 14.5 GPM
- MAXIMUM HEAD: 730'
- IMPELLER DESIGN: Floating Stack
- BODY CONSTRUCTION: Cast Iron
- HORSEPOWER: 2.0
- MOTOR TYPE: 2-Compartment Dual-Voltage; ODP
- VOLTAGE: 1ø, 115/230V
- MAXIMUM LIQUID TEMPERATURE: 120°F/49°C
Franklin Electric High Performance Booster Pump Curve
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Resources
Resources
Franklin Electric High Performance Booster Pump Resources
Franklin Electric Booster Pumps Product Pages
Franklin Electric High Performance Booster Pump Product Pages
Franklin Electric High Performance Booster Pump Owner's Manual
